Cetop 3 modular valves 39 SERIES
Cetop 3 modular relief valve on A and B / 30 lpm H3904
3
Dimensions in mm
$ %
7
Technical data
Max. pressure 250 bar
Max. flow 30 lpm *
Weight 0,9 Kg
Manifold material Aluminium
7
3 7 $ % $ %
3
3 7 $ %
N° Description Q.ty
1 Ø 5,5 through hole for 4
mounting
2 OR 108 i. Ø 8,73 cross 4
section 1,78
3 Bosch Rexroth relief 2
valve VS-30 * depicted
with screw adjustment
* for complete technical information, click on the
blue link.
