P. 510
Load sensing modular Cetop 5 subplates for parallel circuits 52 SERIES
Intermediate subplate / flow restrictor on P / 1 Cetop 5 station / side A-B ports H5203
Dimensions in mm
48 109
32
35 109 80
131
Technical data
Max. pressure 250 bar
Regulated max. flow 70 lpm *
Weight 2,5 Kg T 52
Manifold material Aluminium B A
A / B ports 3/4” G
P
55
2
1
3
4
A B
P T
LS N° Description Q.ty
1 Bosch Rexroth bidirectional flow restrictor OD.21.01-X-36 * 1
T depicted with screw adjustment
2 OR 3068 i. Ø 17.12 cross section 2.62 (P-T) 2
3 OR 2043 i. Ø 10,82 cross section 1,78(LS-FS) 2
4 Ø 8,5 through hole for tie rod 4
* for complete technical information, click on the blue link.
P
A B
3/4" G
510 General catalogue July 2025 edition
