COMPONENTI

OD.15-X-18-Y-Z
2/2 Bosch Rexroth Oil Control S.p.A. 0484090057Z RE 18321-87/04.13

Dimensions
Solenoid operated valves pilot operated poppet type
2-way normally closed

Common cavity, Size 08
RE 18323-25
Edition: 04.2017
VEI-16-08A-NC OD.15 - X - 18 - Y - Z Replaces: 03.2017

Technical data
New VEI-16 family incorporates a new solenoid concept
providing excellent performance and enables cartridges to
work in severe environment. Cartridges also incorporates
advanced design of hydraulic parts providing excellent
hydraulic performance.
Technical data
General
Weight 0.15 kg (0.33 lbs)
Installation orientation Unrestricted
Ambient temperature range -30 to 90 °C (-22 to 194 °F)
Hydraulic
PATENT PENDING Max. operating pressure 350 bar (5000 psi)
Ordering code Flow range 0.5 - 40 l/min (0.1 - 11 gpm)
Fatigue cycle life 2 million cycles at 350 bar
150000 cycles at 420 bar
04.84.09.00 57 Z 00 * Max. internal leakage: 5 drops/min. for X= 01,05,07
20 drops/min. for X= 31,03,09
Switching time Opening ≤ 50 ms
Series 0/A to L Closing ≤ 100 ms
unchanged performances and dimensions
Fluid temperature range -20 to 80 °C (-4 to 176 °F)
Fluids: Mineral-based or synthetics with lubricating properties at
Logic element, pressure viscosities of 20 to 380 mm /s (cSt)
2
compensator with static load sense Version and options standard
Installation torque 39 - 51 Nm (29 - 38 ft-lbs)
Recommended degree Nominal value max. 10 µm
SPRINGS of fluid contamination (NAS 8) ISO 4406 19/17/14
Bias spring MTTFd 150 years see RE 18350-51
Common cavity, Size 12 bar (psi) Cavity CA-08A-2N see 18325-70
Seal kit for X=01,05,07 code RG08A2010520100
= 05 5.5 (80) ±20% material no. R901101437
= 10 10 (145) ±15% Seal kit for X=31,03,09 code RG08A2010530100
material no. R901101544
Seal kit coil code RG01Z0010000100
material no. R930058940
Other technical data See data sheet 18350-50
Electrical
Type Material number Type Material number
Type of voltage DC voltage
048409005705000 R930008062
Coil type D36
048409005710000 R930001081 Supply voltage See data sheet 18325-90
Voltage tolerance against ambient See characteristic curve
temperature
Power consumption 20 W
Type of protection See data sheet 18325-90
